Float Dryer

Standard Features

Float Dryer

Expertise in manufacturing, exporting and supplying Float Dryer with high quality to meet international standards. Float dryer is basically designed to dry printed fabric by hot air. Float Dryer specially working to process printed Fabric like, printed fabric is just floating between hot air cushions from top and bottom sides blown by high-velocity fans. Float Dryer is fully equipped with panels to dry printed fabric. Also, all panels are filled with glass wool that is keeping and avoiding the loss of heat without using any Conveyor. Float Dryer for intermediate drying after bleaching, Mercersing and with many more features.

Cloth Entry: A Set of three curved bar Rubber Sleeve expander. A pair of mechanical cloth guider with adjusting frames to suit cloth width.
Structure: M.S. Stack fabricated from M.S. Plates and flates.

Technical Specification

CYLINDERS: Cylinders of 22” or 30” dia face width from 48” to 120” fabricated from 16 to 10 SWG of 304 or 316 quality stainless steel Argon arc welded consisting M.S. Dished ends and Trunion, Suitable for 40 to 100 P.S.I. Working Pressure. The cylinders mounted on stack running in ball bearing pendestals. Suitable steam inlet out let connection provided. Also, we make Relax Dryer.
